EDWARDS Clevis Pin - ED9-HBA116

• Precision machined Clevis Pin allows users to accurately form material when paired with the Clevis Forming Assembly.
• Requires Clevis Forming Assembly to work with the 20 Ton Horizontal Press.

What our Experts Think

• Essential hardware for secure connections
  The EDWARDS Clevis Pin (ED9‑HBA116) is a critical linking component that ensures reliable pivot and fastener connections in presses, ironworkers, and accessories.
• Precision‑made for smooth fit
  Machined to exact tolerances, this clevis pin provides a snug, wobble‑free fit that enhances alignment and reduces premature wear on mating parts.
• Durable, shop‑ready construction
  Built from rugged, hardened steel to withstand repeated loading and shop‑floor conditions without deformation or failure.
• Easy to install and replace
  Simple design allows quick installation or swap‑out during maintenance — keeping downtime to a minimum.
• Compatible with EDWARDS tooling & machines
  Works seamlessly with related pins, brackets, and linkage points on Edwards presses and ironworkers for dependable performance.

Q&A

Maintenance Tips

• Clean Regularly: Remove dirt, debris, and metal shavings to prevent wear on the pin and mating components.
• Inspect for Wear: Check for bending, cracks, or excessive wear; replace if damaged to maintain safe operation.
• Lubricate: Apply light machine oil to prevent corrosion and ensure smooth pivoting.
• Secure Properly: Ensure cotter pins or retaining clips are correctly installed to prevent accidental dislodging.
• Protect from Rust: Store in a dry environment and lightly oil steel surfaces when not in use.
